Let’s have a look at this article, on how to install System Center 2022 virtual machine manager (SCVMM) console on Windows Server 2022 for managing the VMM Management server. Microsoft System Center Virtual Machine Manager (VMM) is available for a long time, many users used this as the primary tool for managing the physical and virtual environment, but these days Cloud is playing more and more a huge role in the infrastructure. Tools are also switching to Microsoft Azure or Windows Admin Center. You have some strong tools that can manage your infrastructure.
Install Microsoft System Centre 2022 Virtual Machine Manager
Let’s start the process to install System Center 2022 Virtual Machine Manager. Download System Center 2022 Virtual Machine Manager from Microsoft Website.
After downloading the SCVMM_2022.exe file, we are ready to run the setup.exe file.
System center 2022 installation wizard, click next.
Accept the license agreement and then click next.
Select the location where you wish to extract the files and then choose next.
The setup is ready to extract the files, review the destination location and then click extract.
Microsoft System Center 2022 virtual machine manager extracting files.
Click Finish
Install System Center 2022
Open the SCVMM extracted location and run the installer file setup.exe.
This System Center 2022 Virtual Machine Manager Installation window. Click on install.
Default running process
Tick the box features to install (VMM management server and VMM console) and then choose next.
Enter the product registration information of the system center and then choose next.
Read and Accept the license agreement and then choose next.
System Center 2022 setup wizard “Diagnostic and Usage Data” click next.
Choose whether you need to use Microsoft Update or not and then click next.
Select the installation location for the system center and then click next.
“Prerequisites that weren’t found on the server will be listed in the prerequisites check dialog window”
Prerequisites failure. Please bear in mind we need to install the following prerequisites.
Windows Preinstallation Environment features “Windows Assessment and Deployment Kit”.
SQL Server for the installation of the SCVMM database.
After installing the required prerequisite you need to reboot the server.
Microsoft system center 2022 required a minimum of 16 GB of Ram, but I am testing in a lab. Click next
After restarting the system center computer and then run the setup again following the above steps.
System Center Database Configuration
Provide information about the database for the system center you would like to use and then choose next.
Configure a service account for system center 2022 and Distributed Key Management. Click on Select.
Enter the account name and then click ok.
Select next
For system center port configurations, click next.
For library configuration settings, choose next.
Review the system center installation summary and then click on the Install button to start the process.
SCVMM installation feature is in progress.
The Microsoft system center 2022 virtual machine manager setup successfully completed. You can tick the box for updates after the successful installation. Tick the box if you want open the VMM console when the wizard closes.
Login
Virtual machine manager.
